Product Details
＋| Product Attribute | Attribute Value |
|---|---|
| Case Type | DCC |
| Configuration | Open Frame |
| Dimensions | 15.00" L x 4.88" W x 4.55" H |
| Frequency, Input | 47 to 63 Hz |
| Input Voltage | 100 VAC ; 110 VAC ; 115 VAC ; 120 VAC ; 127 VAC ; 190 VAC ; 200 VAC ; 220 VAC ; 230 VAC ; 240 VAC |
| Line Regulation | ±0.05% |
| Load Regulation | ±0.05% |
| Mounting Type | Panel Mount |
| Number of Outputs | 3 Output |
| Operating Temperature | 0 °C |
| Operation | Linear |
| Output Current | 12A@5V, 3.4A@12V, 3.4A@-12V |
| Output Power | 142 W |
| Output Type | Triple Output |
| Output Voltage | 5 VDC, 12 VDC, -12 VDC |
| Primary Type | AC-DC |
| Product Header | Linear Power Supply |
| Response Time | 50 us (Max.) |
| Series | |
| Special Features | Remote Sense |
| Standards | UL Listed, CSA Certified, CE Marked and TÜV Approved |
| Time, Response | 50 us (Max.) |
| Type | Embedded |
| Voltage, Input Range | 100-264 VAC |
| Voltage, Output 1 | 5 VDC |
| Voltage, Output 2 | 12 VDC |
| Voltage, Output 3 | -5 VDC |
Overview
Description
Power-One produces the industry's broadest selection of Linear power supplies with output voltages from 5 volts through 250 volts. Rugged technology and proven design merge to create quiet, highly-regulated, dependable DC power. The Linear power supplies are approved to domestic and international regulatory standards, and are CE Marked to the Low Voltage Directive (LVD).
Features
