Product Details
＋| Product Attribute | Attribute Value |
|---|---|
| Configuration | Enclosed |
| Current, Peak | 5A |
| Dimensions | 4.53L x 0.89" W x 3.48" H (115.0mm x 22.5mm x 88.5mm) |
| Efficiency | 0.86 |
| Family Name | DNR Series |
| Input Voltage | 100 VAC ; 110 VAC ; 115 VAC ; 120 VAC ; 127 VAC ; 190 VAC ; 200 VAC ; 220 VAC ; 230 VAC ; 240 VAC |
| Isolation Voltage | 3kV (3000V) |
| Mounting Type | DIN Rail Mount |
| Number of Outputs | 1 Output |
| Operation | Switching |
| Output Current | 5 A |
| Output Power | 120 W |
| Output Voltage | 24 VDC |
| Primary Type | AC-DC |
| Series | |
| Special Features | Adjustable Output Voltage ; DC Input Capable |
| Type | Industrial |
| Voltage, Input Range | 90-132/180-264 VAC |
Overview
XP Power DNR120-480 Series – 120-480 Watt AC-DC Power Supplies:
Features:
